A d v a n c e d S t r u c t u r e s S e t
H u m a n L e g M o d e l
14
012-12719B
Human Leg Model: Details
Knee Forces
Directly measure the force needed to support the leg at various angles.
Leg Model
The articulated leg uses a rubber band (not included) as the quadriceps muscle and has a Load Cell on the foot to
measure the force that the “toe” exerts on the ball. The impulse (area under the curve of force versus time) is
equal to the resulting momentum of the ball.
The Load Cell represents
the quadricep muscle in
the upper leg.
W
Large Table Clamp
Load
Cell
Load Cell Amplifier
