Advanced Structures Set
ME-6992B
®
1
Included Items Qty Included Items Qty
1. #5 Beam (24 cm long) 24 16. Drive Wheel and Tire 4
2. #4 Beam (17 cm long) 54 17. Straight Connector 24
3. #3 Beam (11.5 cm long) 54 18. Structures Rod Clamp 2
4. #2 Beam (8 cm long) 24 19. Nut and Bolt for PAStrack 6
5. #1 Beam (5.5 cm long) 24 20. Screw (6-32) 300
6. #3 Flexible Beam (11.5 cm) 16 21. “O” Ring 12
7. #4 Flexible Beam (17 cm) 16 22. Pulley 12
8. #5 Flexible Beam (24 cm) 16 23. Collet 24
9. Flat 3 X 4 Beam (19 cm) 16 24. Spacer 12
10. Flat #4 Beam (17 cm) 16 25. Sliding Connector 12
11. Flat 2 X 3 Beam (12.5 cm) 16 26. Angle Connector 24
12. Flat Connector 6 27. Cord Tensioning Clip 32
13. Full Round Connector 6 28. Yellow Cord 1 roll
14. Half Round Connector 42 Force Structures Bracket (not shown) 2
15. Axle (2 each of 3 lengths) 6 Storage Box (not shown) 1
