Cable stayed bridge details – PASCO ME-6992B Advanced Structures Set User Manual
Page 44
®
A d v a n c e d S t r u c t u r e s S e t
C a b l e S t a y e d B r i d g e
40
012-12719B
Cable Stayed Bridge Details
Half
Round
#1
#2
#5
#2
#1
Angle
Connector
Cord
Tensioning
Clip
Cord
Tensioning Clip
Cord
Tensioning
Clip
Cord
Tensioning
Clip
Connect two
cords to each
cord tensioning
clip.
#1
Axle
Collet
#5
Flat
Connector
#3
#3
#1
Half
Round
Tower Base Detail
Tie a knot in one end of the
cord and thread the cord
through a hole on the half
round connector.
