Diamond Products SL User Manual
Page 35
99MS-60114-50 3401019 Drive Wheel Comp.
1
99MS-60139-06
3401943 IdlerPulley Ø 200 mm standard 6
2
0000-60114-01
3400182 Central tube 1
3
0000-60114-02
3401266 Cross Pipe pc. 2
4
0000-60114-03
n/a Cutting pulley support short 2
5
0000-60114-05
341267 Cross clamp 8
6
0000-60114-06
3400936
Extension tube 2
7
0000-60114-35
3400937 Extension tube short 2
8
0000-60114-07
3401200
Pulley support short 1
9
0000-60114-08
n/a
Pulley support long 1
10
0000-60114-09
n/a Plate 2
11
0000-60114-38
n/a
Plate for gear 1
12
0000-60114-12
n/a
Support 1
13
0000-60114-13
n/a Bushing sleeve 4
14
0000-60114-14
n/a
Threaded pivot block with bushing
1
15
0000-60114-15
n/a Spacer 1
16
0000-60114-16
n/a Pivot block handle 1
17
0000-60114-17
n/a
Shaft carriage
1
18
0000-60114-18
n/a
Worm gear 1
19
0000-60114-22
n/a
Central tube 1
20
0000-60114-25
3401256 Spur-toothed wheel 1
21
0000-60114-26
n/a
Support
1
22
0000-60114-28
n/a
Pan head screw
3
23
0000-60059-32
n/a Flange 1
24
0000-60059-33
n/a
Ring
1
25
0000-60072-26
n/a Flange plate 1
26
0000-60086-51
n/a
Snap ring 2
27
0000-60086-52
n/a Spacer 1
28
0000-60086-53
3401050
Driven shaft
1
29
0000-60086-54
n/a Flange 1
30
0000-60086-68
3401951
Lining
1
SL9910
Page 35
