Diamond Products SL - Manual (Page 3)

0.4 Table of contents
0.1 Introduction 2
0.2 Validity of this Operation Instruction 2
0.3 System range definition 2
0.4 Table of contents 3
1 Safety instructions 4
1.1 Basic provisions 4
1.2 Designated usage 6
1.3 Before starting work 6
1.4 During sawing 7
1.5 After finishing work 7
2 Technical Data 8
2.1 Dimensions 8
2.2 Attachable equipment, hydraulic 8
2.3 Attachable electric motor, electric 9
2.4 Design 10
2.5 Function with hydraulic drive 11
2.6 Funktion electric drive 12
2.7 Protection material 13
3 Preparation for work 14
3.1 Procedure 14
3.2 Select drive unit and sawing
motor (hydraulic)
15
3.3 Calculation of rope length 16
3.4 Secure construction site 17
3.5 Secure part to be sawn out 17
4 Set-up 18
4.1 Fastening of system 18
4.2 Connecting the drive unit 20
4.3 Connecting the electric module 21
4.4 Mounting of rope 22
4.5 Mount protection hoods 23
4.6 Water cooling 23
4.7 Connection of water in case of using a
hydraulic unit
23
4.8 Connection of water in case of using
electric motor "EM"
24
5 Sawing 25
5.1 Before sawing 25
5.2 Sawing, hydraulic 25
5.3 Sawing, electric 26
5.4 Trouble shooting 27
5.5 After sawing 27
6 Maintenance 28
6.1 Maintenance table 28
7 Repair 29
7.1 Connection and repair of rope 29
7.2 Connecting the rope by joint lock 29
7.3 Connecting the rope by repair sleeve 30
7.4 Connecting the rope by threaded lock 31
8 Transportation, shut-down , storage,
disposal
32
8.1 Transportation 32
8.2 Shut-down, storage 32
8.3 Disposal 32
8.4 Accessories 32
9 Spare parts list 33
SL
sl9806e page 3
