Diamond Products CB66DS - Manual (Page 6)

6075214 Engine Assembly - CB66D Power Unit
1
3
4
5
8
6
13 15
7
14
16
2
15
9 10
11
12
ITEM PART NO. QTY. DESCRIPTION
1 2603306 1 John Deere 66HP Engine (Rebuilt for CB66D)
2 Exhaust Bracket JD66 1 Exhaust Bracket, (Part of JD 66HP Engine)
3 6075220 1 Muffler Assy. (Rebuilt for CB66D)
4 6075215 1 Air Cleaner Assy. (Rebuilt for CB66D)
5 6075217 1 Bracket Weldment, Engine
6 2601686 1 Heat Exchanger EK-714-T
7 2900086 8 Cap Screw, Hex Hd., 1/2-13 x 1"
8 2900512 6 Cap Screw, Hex Hd., 5/8-11 x 1-1/4"
9 2900138 2 Cap Screw, Hex Hd., 5/16-18 x 1"
10 2900022 2 Flat Washer, 5/16" SAE
11 2900031 2 Lock Washer, 5/16" Split
12 2900141 2 Hex Nut, 5/16-18
13 2900014 6 Flat Washer, 3/8" SAE
14 2900006 4 Lock Washer, 3/8" Split
15 2900005 6 Cap Screw, Hex Hd., 3/8-16 x 1"
16 2900033 2 Hex Nut, 3/8-16
6
