H30 Operation Manual Houston Street Technologies
15
10. Digital Outputs
Below is a list of settings for the (4) digital outputs currently available. Contact HST for additional output
settings.
DIGITAL OUTPUT SETTING DESCRIPTION/USE
SWITCHED POWER POWER SUPPLIED WHEN CONTROLLER IS
TURNED ON
AUDIBLE ALARM USE TO DRIVE AN EXTERNAL WARNING/
SHUTDOWN ALARM
WARNING LIGHT USE TO DRIVE AN EXTERNAL WARNING
LIGHT, MIMICS AMBER LED
SHUTDOWN LIGHT USE TO DRIVE AN EXTERNAL SHUTDOWN
LIGHT, MIMICS RED LED
11. Security
STARTUP SECURITY
A 4-digit code can be used to prevent use of the controller by unauthorized operators. When STARTUP
SECURITY is enabled, the user will be prompted for a 4-digit code after the controller is turned on. If entered
correctly the controller will continue on to the Operation Screen.
To enable/disable STARTUP SECURITY:
1) Press ENTER while at the Operation Screen to access the Main Menu.
2) Use U/D buttons to highlight UTILITIES and press ENTER.
3) Use U/D buttons to highlight STARTUP SECURITY and press ENTER.
4) To enable, enter a new 4-digit code.
5) To disable, enter the same 4-digit code used to enable STARTUP SECURITY.
CONFIGURATION SECURITY
A 4-digit code can be used to prevent unauthorized operators from changing controller settings. If
CONFIGURATION SECURITY is enabled settings cannot be changed without first disabling
CONFIGURATION SECURITY. Note that CONFIGURATION SECURITY and STARTUP SECURITY are
two different security options and do not share their 4-digit codes with each other.
To enable/disable CONFIGURATION SECURITY:
1) Press ENTER while at the Operation Screen to access the Main Menu.
2) Use U/D buttons to highlight UTILITIES and press ENTER.
3) Use U/D buttons to highlight CONFIGURATION SECURITY and press ENTER.
4) To enable, enter a new 4-digit code.
5) To disable, enter the same 4-digit code used to enable CONFIGURATION SECURITY.
