Sheet3 – Diamond Products CB66DS User Manual
Page 16
6075218 Hydraulic Assembly Parts List
ITEM
PART NO.
QTY.
DESCRIPTION
1
6075162
1
Frame, Base, Weldment CB66D
2
3202198
1
Flow Meter
3
3200689
1
Manifold Block
4
3200155
1
Fitting, 1/2" M. Pipe to 3/4" M. Garden
5
3200595
1
Fitting, 1/2" F. Pipe to 3/4" F. Garden
6
3200020
4
Fitting, 1/2" MPT to 1/2" Hose Barb
7
3200740
1
Pressure Gauge
8
2502082
1
Motorized Flow Control
9
3200008
1
Close Nipple, 1/2" NPT
10
3201635
1
Flow Control Valve FCV6-16
11
3201610
1
Flow Control Valve RV5-10
12
3205573
1
#4 Adaptor Plate
13
2603301
1
Hydraulic Pump
14
3201313
1
Hydraulic Coupling 1"
15
3200665
1
Hydraulic Nipple 3/4"
16
3200762
1
Fitting, 1" NPT x 1" MJIC Bulkhead w/Nut
17
3201283
1
3/4" All Male Pipe Tee
18
3205593
1
3/4" MJIC x 3/4" FPT Adaptor
19
3200398
1
3/4" MPT x 3/4" MJIC Bulkhead Adaptor
20
3200745
1
3/4" MORB x 3/4" FPT Adaptor
21
3200757
1
3/4" Run Tee
22
3201393
1
3/4" MPT x 1/4 FPT Reducer Bushing
23
3201306
1
#12 MOR PLug (3/4" O-Ring)
24
3201261
2
3/4" MJIC x 3/4" MPT x 90 DEG
25
3200739
2
12 MORB x 12 MJIC Adaptor
26
3200725
1
6 MJIC x 6 MORB x 90 DEG
27
3200758
1
4 MORB x 4 MJIC Adaptor
28
3202202
1
1/4" ST EL Swivel
29
3200724
1
In-Line Filter
30
3200720
1
6 MJIC x 4 MPT
31
3202217
1
1" MPT x 3/4 MJIC 90 Deg
32
3202059
1
5/8" JIC Cap
