Diamond Products CB66DS - Manual (Page 17)

6075218 Hydraulic Assembly Parts List
ITEM
PART NO.
QTY.
DESCRIPTION
33
3202060
1
Fitting, 5/8" MJIC x 5/8 MJIC Bulkhead w/Nut
34
2900512
2
Cap Screw, Hex Hd., 5/8-11 x 1-1/4"
35
2900113
2
Lock Washer, 5/8" Split
36
2900057
2
Cap Screw, Hex Hd., 3/8-16 x 3-3/4"
37
2900014
2
Flat Washer, 3/8" SAE
38
2900006
22
Lock Washer, 3/8" Split
39
2900033
2
Hex Nut, 3/8-16
40
3202062
1
1" MJIC x 1" MJIC x 1" FJS Tee
41
3200495
1
1" FJIC x 3/4" MJIC Adaptor
42
3200714
2
1" FJS x 1" MJIC x 90 Deg
43
3200287
1
Adapter, 5/8" O-Ring to 1/2" M. JIC
44
3202061
1
Fitting, 5/8" MORB x 5/8" MJIC x 90 DEG
45
3200783
2
Reducer, 1-1/2" NPT x 1" NPT
46
3200755
2
Adaptor, 3/4" NPT x 1/2" NPT
47
3200289
3
Elbow, 1" M. Pipe to 1" M. JIC
48
3200663
2
Fitting, 1" NPT x 1" MJIC
49
2601686A
1
Heat Exchanger Body
50
3202063
1
Water Hose, 1/2" I.D. Pushlok-Black x 40"L
51
3202064
1
Water Hose, 1/2" I.D. Pushlok-Black x 42" L
52
3202065
2
Hyd. Hose Assy. - 3/4"
53
3200736
1
Fitting, 3/4" FJS x 3/4" MJIC x 90 DEG
54
3202066
1
Hyd. Hose Assy. - 3/4"
55
3202067
1
Hyd. Hose Assy. - 3/8"
56
3201461
1
Fitting, 1/2 M JIC to 1/2 M Pipe 90 Elbow
57
3202068
1
Hyd. Hose Assy. - 3/4"
58
3202069
1
Hyd. Hose Assy. - 1/2" w/90 Deg.
59
3202071
1
Hyd. Hose Assy. - 1"
60
3202072
1
Hyd. Hose Assy. - 1"
61
3202074
1
Hyd. Hose Assy. - 1"
62
3202058
1
Oil Drain Hose, Hyd. Hose Assy. - 5/8"
63
2900013
12
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
64
2900005
8
Cap Screw, Hex Hd., 3/8-16 x 1"
17
