H30 Operation Manual

Houston Street Technologies

ESP - DUAL VALVE

A dual-valve feed system is comprised of dual 2-position valves that use one solenoid each to control hydraulic oil

flow, and ultimately the feed direction. The first valve is an ON/OFF valve that controls hydraulic oil flow to the

feed system, while the second valve determines the direction of the feed rollers.

FEED CONTROL

Option to control feed rollers, use OPEN TO RUN to allow
rollers

to feed forward in the event of a relay or solenoid

failure, use CLOSE TO RUN to prevent wheel operation in

the event of a relay or solenoid failure

ENGAGE SPEED

Minimum engine RPM at which the feed rollers will begin

feeding forward

DISENGAGE SPEED

Engine RPM that the feed rollers will reverse

FEED FORWARD

The digital output used to control the feed forward solenoid

FEED REVERSE

The digital output used to control the feed reverse solenoid

REVERSE TIME

Length of time the feed rollers will be reversed

MANUAL FORWARD

Digital input used to manually forward the feed rollers when

the engine is running

MANUAL REVERSE

Digital input used to manually reverse the feed rollers when

the engine is running

To enable/disable ESP:

1) Press ENTER while at the Operation Screen to access the Main Menu.

2) Use U/D buttons to highlight OPERATING MODE and press ENTER.

3) Use U/D buttons to highlight ESP.

4) Use L/R buttons to ENABLE or DISABLE.

(ESP settings can be configured by highlighting CONFIGURE ESP after it has been enabled.)

When purchasing your controller you must specify the feed system that you will be using, controllers do not come

with both the single- and dual-valve system controls enabled.

NOTE: The above operating modes are included in the full feature H30. Your H30 may not include all of the

above operating modes.

SCREENSHOT - ESP DUAL VALVE

ESP SETUP - DUAL VALUE

FEED CONTROL: OPEN TO RUN
ENGAGE SPEED: 2200 RPM
DISENGAGE SPEED: 1800 RPM
FEED FORWARD: D/O#
FEED REVERSE: D/O#
REVERSE TIME: .03 SECONDS

MANUAL FORWARD: D/I#
MANUAL REVERSE: D/I#

RETURN TO OPERATING MODE
