TO: ENGINE
HARNESS
THROTTLE
UP/DOWN
GREEN (GROUND)
GREEN (GROUND)
YELLOW
RED (POWER)
BATT.
IGN.
ACC.
RED (POWER) FROM
ENGINE HARNESS
#6075212 CB-66D Dash/Control Panel Wiring Diagram
TRAILER
PLUG
SOCKET
A
GND
Tm
S
RT
LT
CANTRAK
CONTROL
FUEL GUAGE
FUEL SENDER
(ON FUEL TANK)
S
I G
LIGHT
S
GND
IGNITION
SWITCH
CARTRIDGE
PSI
MANIFOLD
+
_
FRAME
GROUND
BAR BATTERY
BLACK (THROTTLE UP)
ORANGE (THROTTLE DOWN)
GREEN (GROUND)
GREEN (GROUND)
BLACK (CARTRIDGE)
WHITE (CARTRIDGE)
BLACK (CARTRIDGE)
WHITE (CARTRIDGE)
RED (POWER)
41
