MAINTAINENCE AND REPAIR MANUAL
UPLS-2400-SS/2300-SS
MAGNUM VENUS PLASTECH REV 1.13
APRIL 2010 PAGE 45
CHAPTER 6-Installation
INSTALLATION OF THE FLUID SECTION
•
Before installing the Fluid section, Move the Piston Rod assembly up and down a few times to
make sure assembly is moving freely.
•
Place the Fluid Section on the bottom mount and install the pin.
•
Tilt the Fluid Section up and install the upper pin.
•
Install Surge Chamber/Filter Assembly.
•
Tighten Packing nut by hand.
•
Turn air pressure to a very low setting, just enough to cycle the Fluid Sections.
•
Cycle the Fluid Sections a few times very slowly to insure that the Fluid Section is moving freely.
•
Remove Pickup Wand assembly/feed hoses from solvent.
•
Install Pickup Wand assembly/feed hoses.
•
Using the correct size Allen wrench, tighten the Packing Nut down. The packing nut must be tight
enough to compress the packings but not so tight that it does not allow the Piston Rod to move
up and down.
•
Put approved lubricant into the Packing Nut reservoir.
•
Set operating pressure at 0 psi.
•
Put Pickup Wand back into material and /or turn the feed line back on.
The rebuilt Fluid Section is now ready for start up.
