MAINTAINENCE AND REPAIR MANUAL
UPLS-2400-SS/2300-SS
MAGNUM VENUS PLASTECH REV 1.13
APRIL 2010 PAGE 15
CHAPTER 2-Getting Started
The MVP UPLS-2300/2400 Fluid sections are used in multiple configurations. This manual only covers
the disassembly/assembly of the fluid section itself. Generic references are used when referring to other
components that may be connected to the fluid section. Please refer to the specific unit manual for these.
As you disassemble the equipment, lay out the components in the correct order and direction, and have
all current component drawings available to refer to prior to disassembly. This will help in the reassembly.
Please contact your local MVP Distributor or download the current drawings at
WWW.MVPIND.COM
ITEMS AND TOOLS NEEDED
.
•
¼” wooden dowel-6”
•
12” adjustable wrench
•
Set of open end wrenches
•
Pliers
•
Wire brush
•
Table mounted, soft jawed vice.
•
Approved lubricant and grease for material being used.
•
Semi Permanent Loctite (Blue) or equivalent liquid thread lock.
•
Fluid Section Repair Kit (Please reference drawing sets that were included with the unit for
part numbers.)
o Note: The –SK (Seal Kit) only comes with seals and o-rings. The –RK (Repair Kit)
comes with seals, o-rings, balls and springs.
o Note: The Kalrez o-rings that are used on the UPLS-2300-SS Fluid Section are not
included in any repair/seal kit and must be ordered separately.
WARNING!!
Due to high pressures and temperatures that are associated with some materials please
refer to CHAPTER 7-System Start Up, before running a new or rebuilt fluid section.
