UltraBond 10:1 Operations Manual
Rev. 12/2012 Page | 29
Mixing and Dispensing:
1. Attach static mixer to outlet on dispensing head / gun, apply lubricant to threads prior to attachment
(see fig. 34 & 35)
fig. 34 fig. 35
2. Slowly adjust the ram activator feed pump to the appropriate pressure as needed to feed the main
activator pump.
3.
To build fluid pressure, on the adhesive pump push the priming button (09188) located on the air
manifold (see figure 36).
Fig. 36
4.
While pushing the priming button in, slowly increase the adhesive pump regulator, 30 to 40 psi as a
starting point. Once pump has come to a stop, release priming button.
5.
Open dispensing block and allow mixed material to flow out of mixer into a container for 4-5
seconds
6. Begin dispensing a bead of material and check for mix by reviewing uniformity of color (see fig. 37)
fig. 37
