UltraBond 10:1 Operations Manual
Rev. 12/2012 Page | 20
Priming the Unit:
Pre Startup Instructions:
1. Check all hoses for wear or damage, replace if necessary.
2. Check to be sure you have appropriate quantities of Adhesive and Activator to complete the job.
3. Check and repair or replace any damaged items before starting a job.
4. Located on the Ram Adhesive unit check and adjust the Ram lower limit. By adjusting the APD-1011
bracket the RAM stop position can be adjusted (see “Adjust the Drum Low Level Limit” below).
Priming of Unit Air and Solvent
:
1. Close the main inlet air valves on the main air manifolds (see fig. 12)
Fig. 12
2. Connect 1/2 inch main air supply to the Air Manifold (see fig. 12)
3. Turn all regulators counterclockwise to full off and close all ball valves on the Adhesive unit
4. Turn air regulators down and close all ball valves on the Activator Ram unit as well
5. Make sure Ram control levers are in “neutral” position on both rams (see fig. 13 & 13b)
Fig. 13 Fig. 13b
Connect the air supply to the
supplied fitting 1/2"nps.
