UltraBond 10:1 Operations Manual
Rev. 12/2012 Page | 22
Priming of Adhesive Ram Pump:
1. Fill solvent cups with throat seal liquid (see fig. 16)
Fig. 16
2. Open the ball valve off the regulator and gauge marked airlift cylinder (see figure 18).
3. Open ram control lever to “up” position (see fig. 17)
Fig. 17
4.
Slowly turn up ram pressure regulator (marked AIR LIFT) to 10 -20 psi (see figure 18)
Fig. 18
5.
Ram should begin to lift, check for hoses catching or kinking
6. Allow ram to go to full “up” position (clearance for drum)
