Magnum Venus Plastech ULTRABOND 10:1 ADHESIVE UNIT User Manual
Page 19
UltraBond 10:1 Operations Manual
Rev. 12/2012
Page | 19
9.
Attach the Adhesive Hose from the gun to the Adhesive pump (see fig. 9)
Fig. 9
10. Connect the air supply to the Air motor valve (see fig. 10)
Fig. 10
11. Connect the Air supply and valve to the Air Motor (see fig. 11 & 11b)
Fig. 11
Fig. 11b
