UltraBond 10:1 Operations Manual
Rev. 12/2012 Page | 21
6. Open main air feed ball valve and listen for air leaks. The ball valve has a safety relief port and air
will leak from the port until the valve is fully open or closed.
7. Secure all fittings and correct leaks if found
8. Fill Flush Tank with appropriate cleaning agent or place solvent pump onto an approved container
full of the cleaning agent.
9. Close the relief valve on the top of the Flush Tank.
10. Open the Ball Valve and slowly turn up regulator pressure to Flush Tank or solvent pump, if pump is
used turn up regulator until pump begins stroking (see fig. 14)
Fig. 14
11. Secure all solvent leaks, if any
12. Bring solvent pump pressure up to 35–40 psi (2.2 - 2.8 bar) on regulator gauge or 50 psi (3.5 bar) for
flush tank. (reference fig. 14)
13. Wait for solvent pump to stall or stop
14. Test flush system on gun block, by pressing the flush button, test both solvent and air purge (see fig. 15
& 15b). Remove the night cap from the front of the HOD gun
Fig. 15 Fig. 15b
