UltraBond 10:1 Operations Manual
Rev. 12/2012 Page | 18
6. Attach Activator Hose from the Activator Slave Pump to the Activator Manifold (see fig. 6)
Note: Use caution stainless steel hoses kink easily when not under pressure
Fig. 6
7.
Attach the Activator Feed hose from the Activator Slave Pump to the Activator Ram Pump (see fig. 7 & 7b)
Fig. 7 Fig. 7b
8.
Attach Activator Hose from the gun to the Activator Manifold (see fig. 8)
Fig. 8
