9
Z 3600
DIVIDE K FACTOR BY 3600 - This sets the unit for rate per hour; equal to 3600 times rate per second.
NOR##
NORMALIZING FACTOR - Normalizes (averages) the data being received. Higher settings provide more
normalizing (averaging) for a more stable display. Derived from the equation:
(Old Data x "NOR" + New Data)
("NOR" + 1)
FIGUR ##
SIGNIFICANT FIGURE - This sets the amount (1-5) of meaningful figures the unit will display. (RATE DIS
PLAY ONLY). FOR EXAMPLE: If "2" is set as the figure, a rate of 273.45 will be displayed as 270.
DLY##
DELAY FACTOR - The amount of time (02 to 24 sec.) the unit will "look" for valid data, before the display
defaults to zero. (RATE DISPLAY ONLY)
LOC
LOCK - This portion of the menu allows you to:
1) lock the program (presets and front reset are still accessible)
2) lock all (presets, front reset, and program are locked).
LC PRG
LOCK PROGRAM - This will lock the program, but allows the front reset and the presets to be changed when
the unit is in the lock mode.
LC ALL
LOCK ALL - This will lock the program, reset and the presets when the unit is in the locked mode. The
presets can be viewed, but not changed.
CODE
LOCK CODE - This message (code) will flash on display for approximately 3 seconds. It will be followed by a
5 digit number (xxxxx). The number you enter here will be the code to lock and unlock the unit.
RELAY
RELAY - This portion of the menu allows you to set your relay operation variables.
A TOT RELAY A FOR TOTALIZER - When this is selected the user has a choice of having Preset A follow the A
(
tot a ) or C ( tot c ) display.
tot a RELAY A FOR A TOTALIZER - If selected, the A output is activated by A total and user can select auto
recycle with duration of 00.1 to 99.9 sec or latched till reset if 00.0 is programmed.
tot c RELAY A FOR C TOTALIZER - If selected, the A output is activated when C total is equal or greater then
preset A and drops out when C total goes below preset A by selected 0 - 99.9 hysteresis.
A RATE
RELAY A FOR RATE - When this is selected, output A will activate when the Rate of either display A or
display C (user selectable) equals or exceeds preset A. The relay will drop out when the selected rate falls
below preset A by selected 0 - 99.9 hysteresis..
rate a RELAY A FOR A RATE - If selected, the A output is activated when A rate is equal or greater than preset A
and drops out when A rate goes below preset A by selected 0 - 99.9 hysteresis.
rate c RELAY A FOR C RATE - If selected, output A is activated when C rate is equal or greater than preset A and
drops out when the C rate goes below preset A by selected 0 -99.9 hysteresis.
hy ##.# HYSTERESIS OF RELAY - 0 - 99.9 value which user selects as difference between activation and drop out of
output for rate and “C” value. Output activates when value is equal or above preset but only drops out when
value is below preset by selected hysteresis value.
du ##.# DURATION OF OUTPUT FOR A OR B TOTAL - If set 00.1 to 99.9 sec, selected counter autoresets at preset
and output is active for selected time. If set 00.0 counter does not autoreset and output is active as long as
count is equal or above preset.
