Sponsler, Inc.
Model SP2850-TC with MS649
Page 25
DOC#: MN-2850
1
0
0
D
0 (As an example)
100.0 (Flashing)
(Press D for decimal, press C to change sign, i.e. + or -)
ENT
RUN MODE
STEP 11D: Setting the Compensation Input for Manual (Density)
Press
Display
D
MENU Flashes the PRESET
↓
D until
COMP IN
↓
ENT
IN TYPE (Flashes to last type entered)
RTD
↓
D
4-20MA
↓
D
0-5V
↓
D
0-10V
↓
D
MANUAL
↓ (Press D to go to RTD ↓)
ENT (When MANUAL is displayed)
DN
↓ TEMP ↓
(Press B for DN-Density;
D for TEMP-Temperature
ENT (When DN is selected)
ENT DN (Followed by existing value)
CLR
0 (Flashing)
1
2
D
4
(As an example)
12.4 (Flashing)
(Press D for decimal)
ENT
RUN MODE
STEP 12: Setting the Fluid Properties
Press
Display
D
MENU Flashes then PRESET
↓
D until
FLUID
↓
ENT
REF DENS (Followed by existing value)
NOTE: If the compensation input is set for temperature and the flow equation is set for corrected volume, the
reference density needs to be entered only for the density in the run mode. If the reference density is not known,
enter one (1). Realize that when one (1) is entered the density displayed in the run mode will be incorrect.
CLR
0 (Flashing)
6
1
D
2
(As an example)
61.2 (Flashing)
(Press D for decimal)
ENT
*REF TEMP (Followed by existing value)
