Sponsler, Inc. Model SP2850-TC with MS649 Page 20 DOC#: MN-2850
CLR SIGFIG 00
6 Example Only. SIGFIG 06
Key in the desired number of digits for rate display
(SIG FIG indicated how many meaningful digits are shown; trailing zeroes are inserted if necessary)
ENT (SIG FIG Entered) WEIGHT # # (Existing Weight Value)
CLR WEIGHT 00
6 WEIGHT 06
ENT (Weight Entered) RUN MODE
STEP 7: Setting Lockout Code
Press Display
D MENU Flashes to PRESET
↓
D until LOCKOUT
↓
ENT SECUR # # (Existing Value)
SECUR (Security) is the amount of time (seconds) that the unit will `look’ for valid input pulses. If no pulses are
received in the programmed amount of time, the relays will drop out and the unit will display `SECURITY’. The four
digit lockout code must be entered to return to normal operation. Note: Entering 00 will disable the security feature.
This feature is not available with RTD input.
CLR SECUR 00
4 (As an example) SECUR 04
ENT ((SECUR Entered) CODE Followed by Flashing Code Number
CLR 0
1 1 1 1 (As an example) 1 1 1 1 (Flashing)
This is the code used to lock/unlock unit. RECORD FOR LATER USE.
ENT (CODE Entered) RUN MODE
STEP 8: Setting the Communication Out Card (Skip if RS232/422 option is not installed)
Press Display
D MENU Flashes to PRESET
↓
D until OUTCARD
ENT (Unit ID number. Can be any number from 1 to 15) UNIT # # (Existing Value)
CLR UNIT 00
1 (As an example) UNIT 01
ENT (Unit number entered) PL
↓ SER↓ *
ENT BAUDRATE (Flashes followed by last baudrate used)
300
↓
