Liquid Controls SP2850 (MS-649) User Manual
Page 24
Sponsler, Inc.
Model SP2850-TC with MS649
Page 24
DOC#: MN-2850
D
MANUAL
↓ (Press D to go to RTD ↓)
ENT (Selects displayed option)
DN
↓ TEMP ↓ (
(Press B
for DN-Density
D for TEMP-Temperature)
ENT (When DN is selected)
DEFLT DN (Followed by existing value)
CLR
0 (Flashing)
1
D
2
4 (As an example)
1.24 (Flashing)
(Press D for decimal)
ENT
DENS LOW (Followed by existing value)
CLR
0 (Flashing)
1
0
D
0
(As an example)
10.0 (Flashing)
(Press D for decimal)
ENT
DENS HI (Followed by existing value)
CLR
0 (Flashing)
1
0
0
D
0
(As an example)
100.0 (Flashing)
(Press D for decimal)
ENT
RUN MODE
STEP 11C: Setting Compensation Input for Manual (Temperature)
Press
Display
D
MENU Flashes the PRESET
↓
D until
COMP IN
↓
ENT
IN TYPE (Flashes to last type entered)
RTD
↓
D
4-20MA
↓
D
0-5V
↓
D
0-10V
↓
D
MANUAL
↓ (Press D to go to RTD ↓)
ENT (When MANUAL is displayed)
DN
↓ TEMP ↓
(Press B for DN-Density;
D for TEMP-temperature)
ENT (When TEMP is selected)
°C ↓ °F ↓ (Press
B for
°C, press D for °F)
ENT
ENT TEMP (Followed by existing value)
CLR
0 (Flashing)
