Sponsler, Inc. Model SP2850-TC with MS649 Page 19 DOC#: MN-2850
SETUP PROCEDURES CONTINUED
STEP 5: Setting the Counter
Press Display
D MENU Flashes then PRESET
↓
D until COUNT
↓
ENT R0 SP
↓
(RO Reset to 0 `ADD’ or SP: Set to Preset to
`SUBTRACT’)
B or D to move cursor (_) to the desired option Selects R0 or SP
ENT (Selection Entered) * DEC LOC (Decimal Location)
Press the number of the digit that will display to the left of
the decimal. Decimal moves to that location
(Example: 3, the decimal will display to the right of the
third digit 3.21)
ENT (Decimal location entered) CNTENALO
↓
**WAIT** # # (Existing window value)
CLR 0
3 2 0 C (As an example) -320
ENT CNTENAHI
↓
**WAIT** # # (Existing window value)
CLR 0
2 9 2 C (As an example) -292
ENT RUN MODE
*NOTE: The decimal displayed in the `TOTAL’ and `GRAND TOTAL is a dummy. The K-Factor must be divided by a
factor of ten for each digit to the right of the decimal. Example: Decimal Location 3 displays 2 digits to the right of the
decimal. The K-Factor must be divided by 100 for correct totalization and rate indication.
STEP 6: Setting the Ratemeter
Press Display
D MENU Flashes to PRESET
↓
D until RATE
↓
ENT WINDOW # # (Existing Window Value)
CLR WINDOW 00
4 Example Only. WINDOW 04
Key in the desired time (02 to 24 sec.) that the unit will
wait for an input pulse before displaying 0 rate.
ENT (Window Entered) SIGFIG # # (Existing Value)
