Liquid Controls SP2850 (MS-649) User Manual
Page 21

Sponsler, Inc.
Model SP2850-TC with MS649
Page 21
DOC#: MN-2850
D
600
↓
D
1200
↓
D
2400
↓
D
4800
↓
D
9600
↓
(Press D to go to 300
↓)
ENT
PARITY (Flashes, then last parity used)
D
EVEN
↓
D
ODD
↓
D
MARK
↓
D
SPACE
↓ (Press D to go to EVEN ↓)
ENT
RUN MODE
*Unit should always be `SER’, `PL’ is disabled.
STEP 9: Setting the Analog Output
Press
Display
D
MENU Flashes then PRESET
↓
D until
ALG OUT
↓
ENT
ANLG RT (Analog Output for Rate)
D
(Press D to toggle between selections)
ANLG CT (Analog Output for Count)
ENT (To select displayed option)
SET LOW (Flashes to Last Value Stored)
CLR
0 (Flashing)
1
D
2
4
(As an example)
1.24 (Flashing)
(Press D for decimal) In this example 1.24 = 4mA
ENT (Low set at 1.24)
SET HIGH (Flashes to Last Value Stored)
CLR
0 (Flashing)
1
0
0
D
0
(As an example)
100.0 (Flashing)
(Press D for decimal) In this example 100.0 = 20mA
ENT (High set at 100.0)
RUN MODE
STEP 10: Setting Output Frequency
Press
Display
D
MENU Flashes then PRESET
↓
D until
OUTFREQ
↓
