Sponsler, Inc. Model SP2850-TC with MS649 Page 22 DOC#: MN-2850
ENT 20000
↓ (Displays last selection)
D 2000
↓
D 200
↓
D 10
↓ (Press
D to go to 20000
↓)
ENT (To select displayed option) RUN MODE
STEP 11: Setting the Compensation Input for RTD
NOTE: When RTD input is desired, the RTD `R’ input option must be ordered or jumper changes made. See jumper
option on page 24.
Press Display
D MENU Flashes then PRESET
↓
D COMP IN
↓
ENT IN TYPE (Flashes to last type entered)
D 4-20MA
↓
D 0-5V
↓
D 0-10V
↓
D MANUAL
↓
D RTD
↓ (Press D to go to 4-20MA ↓)
ENT (When RTD is displayed) °C↓ °F°↓ (Press B for °C, Press D for °F)
ENT DEFLT TP (Followed by existing value)
CLR 0 (Flashing)
1 D 2 4 (As an example) 1.24 (Flashing)
(Press D for decimal)
(Press C to change sign (+ or - displayed at the left of the display)
ENT RUN MODE
STEP 11A: Setting Compensation Input for Analog (Temperature)
NOTE: If an analog input (mA or V) is desired, the unit must be ordered without the `R’ (RTD) option or jumper
changes made. See `Jumper Options’ page 24.
Press Display
D MENU Flashes to PRESET
↓
D until COMP IN
↓
ENT IN TYPE (Flashes to last type entered)
RTD
↓
