212iLW/242iLW Standalone Keypad
Installation/Programming Manual
Document # 6050700, Rev. 1.1, D2d
2
1. Features and Product
Description
1.1 Keypad Features
• Flush Mount, Single Gang
• Illuminated Backlit Keys
• Keypad Programmable
• Access Control Functionality (242 model)
• Individually Control up to 4 Devices (242 model)
• Keypress Feedback via Built-In Sounder
• Bi-Color Red/Green LED Indicates Relay Status
• Yellow LED Indicates Program Mode
• 120 Users
• Panic and Duress Options
• Single Use Codes
• Lockout Users
• Passage/Toggle Codes
• 10 to 30 Volt DC Operation
• 12 to 24 Volt AC Operation
• 2 Amp Main Relay
• Remote Trigger Input (REX)
• Door Monitor Input
• 2 Year Warranty
1.1.1 Output Functionality Options (242 only)
• Four Independent Relay Outputs
• Four Independent Relay Timers
• All Relay Outputs Assignable By Code
1.1.2 Access Control Features (242 only)
• Lock Release Output With Timer
• Alarm Zone Shunt Relay
• Propped Door Alarm Relay
• Forced Door Alarm Relay
