212iLW/242iLW Standalone Keypad
Installation/Programming Manual

Document # 6050700, Rev. 1.1, D2d

18


Virtual Outputs

Description/Details

Forced Door

This output activates if the door position switch is
opened without entering a valid user code.

OUT2, OUT3,
OUT4, OUT5
(242)

These four independently controlled outputs are
activated by user codes programmed to activate
multiple outputs and the REX function. See
programming commands 59 and 49 in the
Programming section.

Duress (242)

The duress output is activated when a duress
user enters their code. See Duress User in the
Programming section.

Panic (242)

Panic is activated by pressing the * and # keys at
the same time. This is used in case of
emergency to activate an auxiliary device and
should not be used to gain access.

Keypad Active (242)

The Keypad Active output is activated when any
key is pressed. Do not use this output to gain
access.

7.2.2 Audio Alerts

Audio Alerts are produced by the local sounder on the keypad and
can be used as a local propped door alarm or forced door alarm to
free up the relays for other functions.

• Alert #1 is a constant quick beep (¼ second on and ¼

second off).

• Alert #2 is a short beep (100 ms) every two seconds.

• Alert #1 takes priority over Alert #2.

7.2.3 Programming REX Outputs (242 Model)

For wiring information, see section 5.5.

49 # output list # 0 # **

Use this command to program which outputs the REX operates.
1 = LOCK, 2 = OUT2, 3 = OUT3, 4 = OUT4, and 5 = OUT5.
