212iLW/242iLW Standalone Keypad

Installation/Programming Manual

Document # 6050700, Rev. 1.1, D2d

19


Command/Action

Keys to Enter/Details

Command 11. Set
LOCK Time Duration

11 # time # 0 # * * (time = 1 to 255 seconds)

Command 12. Set
OUT2 Time Duration

12 # ttt # mmm # * *

To toggle enter:
12 # 0 # 0 # **

Command 13. Set
OUT3 Time Duration

13 # ttt # mmm # * *

To toggle enter:
13 # 0 # 0 # **

Command 14. Set
OUT4 Time Duration

14 # ttt # mmm # * *

To toggle enter:
14 # 0 # 0 # **

Command 15. Set
OUT5 Time Duration

15 # ttt # mmm # **

To toggle enter:
15 # 0 # 0 # **

Options:

ttt (time units)

Number of time units to operate OUTn when valid
PIN entered (1-255)

Examples:

12 # 1 # 10 # (for 10 seconds)
(1 time unit multiplied by 10 seconds)
12 # 2 # 10 # (for 20 seconds)
(2 time units multiplied by 10 seconds)

mmm (multiplier)

Number of seconds in each time unit (1-255)

Examples:

12 # 15 # 1 # (for 15 seconds)
(15 time units multiplied by 1 second)
12 # 15 # 2 # (for 30 seconds)
(15 time units multiplied by 2 seconds)


Command 44. Set
Propped Door Time

44 # time # 0 # * *

Options:

time

Propped Door Time - rounded down to nearest
10’s of seconds; entered as 00, 10 through 990,
defaults to 30 seconds; entering a time of zero
disables the propped door function.


Command 45. Set
Forced Door Time

45 # time # 0 # * *

Options:

time

Forced Door Time - rounded down to nearest
10’s of seconds; entered as 00, 10 through 990,
defaults to 10 seconds; entering a time of zero
latches the virtual forced door that can be cleared
with any valid PIN or by entering program mode.
