44
PHOTOELECTRIC SENSORS (NON-CONTACT)
The photoelectric sensors are designed to detect an obstacle in the
path of the electronic beam and stop the operator. Includes
mounting brackets.
Models AOMRON E3K-R10K4-NR (retro-reflective), RETROAB
60-2728 (retro-reflective), CPS-UN4 (through beam)
SENSING EDGE (2-WIRE, NON-MONITORED,
CONTACT)
Sensing edges can detect an obstacle upon contact and stop the
operator.
Models G65MG0204, G65MG0205, G65MGR205, and
G65MGS205
SENSING EDGE CHANNEL
Mounting channel for all MG020 type edges.
Model G65ME120C5
ENTRAPMENT PROTECTION DEVICES
MISCELLANEOUS
REMOTE ANTENNA EXTENSION KIT
The remote antenna extension kit allows the antenna to be
remotely installed.
Model 86LM
WIRELESS ACCESS CONTROL RECEIVER
Access control receiver for up to 450 remote controls.
Model STAR450-315
PLUG-IN LOOP DETECTOR
Low power. Conveniently plugs into existing control board.
Model LOOPDETLM
LOOP DETECTOR
Low power loop detectors mounted and wired separately inside
control box.
Model LD7LP
VEHICLE SENSING PROBE
The vehicle sensing probe is buried in the ground and can detect a
car as it approaches and will then open the gate.
Model CP3
SOLAR PANEL KIT - 10 WATT
This kit is to replace or add a solar panel to the operator
application. Up to four solar panels can be connected to the
operator.
Model SOLPNL10W12V (requires 2 minimum)
BATTERY FOR GATE ACCESS SYSTEMS
Gate access system batteries replace or upgrade the gate operator
batteries.
Model 29-NP712 (standard 7 AMP-Hour Battery, 12 Vdc, to
replace original batteries provided with operator, reuse existing
harnesses)
Model A12330SGLPK (upgrade 33 AMP-Hour Battery, 12 Vdc,
includes 33AH harness. Ideal for solar applications and extended
battery backup). For use with Large Metal Control Box ONLY. A
battery tray (model K10-36183) and battery harness
(model K94-36596) are required for 33AH applications.
Two identical 12 Vdc batteries are required for each gate
operator. Do not mix 7AH and 33AH batteries within a gate
operator.
SOLENOID GATE LOCK
The automatic gate lock is a solenoid-driven lock that
automatically unlocks when the gate is open and locks when the
gate is closed. Can be mounted onto a gate or post. Can be
released in case of emergency.
Model GC824-12 (12/24 Vac/dc)
MAGNETIC GATE LOCK
Outdoor magnetic lock, transformer, junction box, mounting plate
and hardware. Not for use with Solar Applications. Must be
powered separately.
Model MG1300 (12/24 Vdc)
TRANSFORMER RUN KIT (OPTIONAL)
Model LA500HDTKITSTD (for Standard Control Box)
Model LA500HDTKITXLM (for Large Metal Control Box)
MISCELLANEOUS
ACCESSORIES
REMOTE CONTROLS
Chamberlain offers a variety of LiftMaster remote controls to satisfy your application needs.
Single-button to 4-button, visor or key chain. The following remote controls are compatible
with operators manufactured by Chamberlain after 1993. Contact your authorized LiftMaster
dealer for additional details and options.
3-BUTTON REMOTE CONTROL
The 3-button remote control can be programmed to control the
operator. Includes visor clip.
Model 893MAX
3-BUTTON MINI-REMOTE CONTROL
The 3-button remote control can be programmed to control the
operator. Includes key ring and fastening strip.
Model 890MAX
KEYLESS ENTRY
Enables homeowner to operate gate operator from outside by
entering a 4-digit code on a specially designed keypad.
Model 877MAX
