27
SET O EN S T LO E
M VE
G TE
OF
5
0
0
80 N
OP N
C
OSE
S
OP
PU PO ER A T C A G NG I ER AT MO I G TT OW C PWR V D AG OS C OD S T TUS
DE T
E I
H
C O E Y S N ER
AC E SO Y
PO ER
ON SW
E P O RD
M T ER N WO K
S T P 1
L M T
2
5
SO A /
CH R ER
J 5
B TT DC OW R
ID E ET
BR RN W YE B U R D BR G N WT YE LU ED
LEARN
BU
SAL
XMITTER
NETWORK
REMOTE CONTROLS (NOT PROVIDED) + ERASE ALL CODES
PROGRAMMING
S T OP N SET CLOSE
MOVE
GATE
5
10
60
OFF ON OP
N
LOSE
ST
OP
NP T POW R B TT HAR I G IM R G TE M V NG A T LOW CC PWR VL D AG OST ODES S ATUS
E I
HA OW LO E
E ES
NT RR
LO K
+
ACC
SS R Y
OWER ON SW
EXP OA
D
ER
E WO K
R E S O B I S T P 1
L M T
2
J5
+
OL R /
HA GER
15
+
B TT + DC POW R
D E ET L RM
GR UND BR GRN WT E LU R D R GRN WT YE B U R D
LEARN
BU
SAL
XMITTER
NETWORK
OPEN
CLOSE
ST
OP
TEST
BUTTONS
RSAL
CE
TER
TWORK
ERASE ALL CODES
1
Press and release the LEARN button (operator will beep and green XMITTER LED
will light).
2
Press and hold the LEARN button again until the green XMITTER LED goes out
(approximately 6 seconds). All remote control codes are now erased.
NOTICE: To comply with FCC and/or Industry Canada (IC) rules, adjustment or modifications of this transceiver are prohibited. THERE ARE
NO USER SERVICEABLE PARTS. Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules and IC RSS-210. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
This Class B digital apparatus complies with Canadian ICES-003.
AVIS : Les règles de la FCC et/ou d’Industrie Canada (IC) interdisent tout ajustement ou toute modification de ce récepteur. IL N’EXISTE
AUCUNE PIÈCE SUSCEPTIBLE D’ÊTRE ENTRETENUE PAR L’UTILISATEUR. Tout changement ou toute modification non expressément approuvé
par la partie responsable de la conformité peut avoir pour résultat d'annuler l'autorité de l’utilisateur de faire fonctionner l’équipement.
Cet appareil est conforme aux dispositions de la partie 15 du règlement de la FCC et de la norme IC RSS-210. Son utilisation est assujettie
aux deux conditions suivantes : (1) ce dispositif ne peut causer des interférences nuisibles, et (2) ce dispositif doit accepter toute
interférence reçue, y compris une interférence pouvant causer un fonctionnement non souhaité.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
REMOTE CONTROLS (NOT PROVIDED)
A total of 50 Security✚ 2.0™ remote controls and 2 keyless entries (1 PIN for each
keyless entry) can be programmed to the operator. NOTE: When the memory is full
the operator will exit programming mode and the remote control/keyless entry will
not be programmed. The memory will need to be erased before programming any
additional remote controls/keyless entries. If installing an 86LM to extend the range
of the remote controls DO NOT bend the antenna.
There are 3 different options for programming the remote control
depending on how you would like the remote control to function. Choose
a programming option:
OPTION DESCRIPTION PROGRAMMING STEPS
Single button as OPEN only Program a single button on the remote
control for open only. The Timer-to-Close
can be set to close the gate.
1. Press and release the LEARN button (operator will beep and green XMITTER LED will light).
2. Press the OPEN button.
3. Press the remote control button that you would like to program.
Single button as OPEN,
CLOSE, and STOP
Program one remote control button as an
open, close, and stop.
1. Press and release the LEARN button (operator will beep and green XMITTER LED will light).
2. Press the remote control button that you would like to program.
Three separate buttons as
OPEN, CLOSE, and STOP
Program each remote control button as an
open, close, and stop.
1. Press and release the LEARN button (operator will beep and green XMITTER LED will light).
2. Press the OPEN, CLOSE, or STOP button, depending on the desired function.
3. Press the remote control button that you would like to program.
The operator will automatically exit learn mode (operator will beep and green XMITTER LED will go out) if programming is successful. To program additional Security✚ 2.0™
remote controls or remote control buttons, repeat the programming steps above.
