TurboVUi Dispatch Software Installation and Configuration Guide
22
After clicking the button, a test will be performed on the target storage location to determine if
the device access speed is sufficient. If the drive speed is too low, the following warning will be
displayed.
Available Disk Space
If Logging is enabled above, the available disk space is listed.
Estimated Storage Remaining
If Logging is enabled above, the estimated time for storing files is listed.
Drive Speed
If Logging is enabled above, an evaluation of the drive speed will indicate OK if satisfactory for logging.
Click the button to save all Dispatch Settings.
Internet Proxy Sub-folder
When the Internet Proxy sub-folder is selected, the following window will be displayed.
This window is used to define Custom Proxy settings when the following combination of requirements exist:

The Local Area Network uses an Internet Proxy, and

GPS mapping using an available Internet mapping service
Actions Folder
When the Actions folder is selected, the following window will be displayed.
This window is used to define specific Actions such as Audio Call, Text Message, or Transmit Emergency. These actions
be can then associated with a USB PTT device (using the
USB Devices folder) or a Toolbar Button (using the Toolbar
Buttons folder) for use by a Dispatcher. Several Actions are pre-defined as indicated above.
To create a new Action, click the button to display the New Action Wizard .
