Conveyor Technologies 1M BOARD CLEANER - Manual

PCB Cleaning System to Automatically
Remove any Foreign Debris Material.
- 1 Meter Long/1 Section
- Hand Crank Width Adjust 2.0” – 16.0”
- Board Edge Clearance = .100” (.60”min).
- Speed Control
- Cycle Count for Roller Life Cycle
- Ionized Air Blower
- PLC Controls with SMEMA Cables
- Cycle Counter
- Steel Welded Frame
- Heavy-duty Aluminum Extruded Rails
- Auto/Manual Select Switch
- E-Stop Push Button
- Digital Roller Height
- Totally Enclosed for Safety w/ E-Stop Interlocks
- Top Side Sticky Roller PCB Debris remover
- Top Side ESD Rotation Brushes with Vacuum
- Barcode Reader
STANDARD FEATURES
PN:
BCS-1M
SPECIFICATIONS
• PCB Size: ................................... Min. 2” X 4”
................................................. Max.16” X 18”
• PCB Height: ............................... 37.5” + - 2”
• Edge Clearance: .... . 3mm from edge of PCB
• Air Requirements:.......... . 1.5 cfm @ 100 PSI
• Power Requirements: ... 15 amps @ 110VAC
• Cycle Time: ............................ 5 – 7 Seconds
BOARD CLEANING CONVEYOR
CUSTOMER SATISFACTION……. “Whatever it takes”
- 18” X 20”, 21” X 24”, 24” X 28” PCB Capability
- Light Tower for Indicating Operator Status
- Auto Width Adjust
- .5 Meter Available without Barcode Reader
OPTIONS
