Semi automatic servo press

The Servo Semi Automatic Press Workstation allows precise control of the
press operating parameters (Force, Distance and Speed) as a self contained
ergonomic solution.
Both force curve and SPC control graphs are displayed for the current product
being processed.
Data for all products are stored in a database and sent to facility mainframe on
demand.
Product recipes (programs) are entered with Pass/Fail characteristics. At the
end of each cycle the system displays and records pass/fail information.
Automatic add on peripherals are available.
PRESS DESCRIPTION
SEMI AUTOMATIC SERVO PRESS
PN:
SAP-12/110-20/36
- 15 inch touch screen operator interface
- Force and SPC graphs shown of product in-process
- Unlimited storage of product profiles
- Display current production run Quantities
- Process stops with unexpected press force at distance
- Windows based PC software
- Bar code ready
- Programmable hold time
- Light curtains for operator safety
CUSTOMER SATISFACTION…………“Whatever it takes”
TOOLING FIXTURES
CONTINUITY CHECK
STANDARD FEATURES
PRESS PLATE WITH PIN CHECK
