Conveyor Technologies WIET-.6M User Manual
Pn:wiet m, Wave input elevator tilt conveyor ths, Standard specific ations
PCB Size
Min: 2.0” x 4.0”
Max: 18.0” x 20.0”
Air Requirement
.3 cfm @ 65 PSI
Power Requirement 110 V AC, 15A
Cycle Time
(Pending W ave Speed)
STANDARD SPECIFIC
ATIONS:
PN:WIET-.6M
WAVE INPUT ELEVATOR TILT CONVEYOR THS
STANDARD FEATURES:
• Edge B elt C onveyor
• Rec eiv es PCB L evel, Lowers and Tilts t o Feed Wave
• Rail Ex tension for Close P ositioning t o
Wave Fingers
• Speed C ontrol Slo w Down for P revious and
Next Machine Speeds
• Adjustable 0 - 8 D egr ee Angle
• Boar d Edge Clear anc e = .100” (.060” min)
• Hand Cr ank Width A djust = 2.0” - 18.0”
• 1/2” Steel Welded F rame
• Totally Enclosed With In terlock ed D oor
OPTIONS:
• 21” x 24”, 24” x 28” PCB C apabilit y
• Auto Width A djust
• Speed Ma tching t o Wave Solder
HEIGHT ADJUSTMENT
:
Input End:
Output End:
28” - 40”
29” - 41”
30-40"
28-38"
6
∞
23.625"
38.000"
5.322"
35
