Chapter 5: Programming commands
33
A776-PG00001 C 12/09
A776 (B780) Programming Guide
Bar codes
Code (hexadecimal)
Command
Page
1D 48 n
Select printing position for HRI characters
100
1D 66 n
Select pitch for HRI characters
100
1D 68 n
Select bar code height
100
1D 6B m d1…dk 00
Print bar code
100
or 1D 6B m n d1…dn
1D 6B m nL nH d1... dn Print GS1 DataBar (formerly RSS), data length specified
103
1D 6B n d1... 00 Print GS1 Databar (formerly RSS), null terminated
103
1D 6B FF n
Print multiple bar codes
103
1D 70 a b c d e f
Select PDF 417 parameters
104
1D 71 a b c d e fL fH Set GS1 Databar (formerly RSS) parameters
102
1D 77 n
Select bar code width
106
Page mode
Code (hexadecimal)
Command
Page
0C
Print and return to standard mode
108
18
Cancel print data in page mode
108
1B 0C
Print data in page mode
108
1B 4C
Select page mode
109
1B 53
Select standard mode
110
1B 54 n
Select print direction in page mode
110
1B 57 n1, n2…n8
Set print area in page mode
111
1D 24 nL nH
Set absolute vertical print position in page mode
112
1D 5C nL nH
Set relative vertical print position in page mode
112
Macros
Code (hexadecimal)
Command
Page
1D 3A
Select or cancel macro definition
113
1D 5E r t m
Execute macro
113
MICR check reader commands
MICR Reading
Code (Hexadecimal)
Command
Page
1B 77 01
Read MICR data and transmit
114
1B 77 02
Read MICR data and transmit (B780 only)
114
1B 77 52
Transmit last MICR read
115
MICR Parsing
Code (Hexadecimal)
Command
Page
1B 77 50
Define parsing format, save in NVRAM
115
1B 77 70
Define parsing format, do not save permanently
115
