Chapter 4: Programming the Printer 26
A776 (B780) Programming Guide A776-PG00001 C 12/09
Print zones for slip station
The slip station prints characters (standard and
compressed pitch) and graphics in a print zone of 77mm
(3.0”) wide on a slip or form.
• Standard pitch: 42 characters (columns) per line
• Compressed pitch: 51 characters (columns) per line
•
21 rotated characters
• 210 adjacent bits of graphics
• 420 addressable positions
The print line height of 7x7 dot characters is
2.46mm (.097”). With three-dot spacing, the print
line height is 3.53mm (.139”). See the following
illustration (not to scale). To print as close to the
bottom of the slip as possible without the slip leaving
the feed rollers, use the “Print and feed n lines”
(1B 64 n) command, with n = 0.
Slip Print
Zone
