Chapter 5: Programming commands 93
A776-PG00001 C 12/09 A776 (B780) Programming Guide
4 = Transmit receipt paper status
Bit Status Hex Decimal Function
0 Off 00 0 Fixed to off
1 On 02 2 Fixed to on
2 Off 00 0 Receipt Paper adequate
On 04 4 Receipt Paper low
3 Off 00 0 Receipt Paper adequate or Door Open
On 08 8 Receipt Paper low or Door Open
4 On 10 16 Fixed to on
5 Off 00 0 Receipt Paper present
On 20 32 Receipt Paper exhausted
6 Off 00 0 Receipt Paper present
On 40 64 Receipt Paper exhausted
7 Off 00 0 Fixed to off
5 = Transmit Slip Paper Status and
6 = Transmit Validation Paper Status
Bit Status Hex Decimal Function
0 Off 00 0 Fixed to Off
1 On 02 2 Fixed to On
2 Off 00 0 Slip paper selected
On 04 4 Slip not selected
3 Off 00 0 Not waiting for slip
On 08 8 Waiting for slip
4 On 10 16 Fixed to On
5 Off 00 0 Slip leading edge sensor:
paper present
On 20 32 Slip leading edge sensor:
no paper
6 Off 00 0 Slip trailing edge sensor:
paper present
On 40 64 Slip trailing edge sensor:
no paper
7 Off 00 0 Fixed to Off
