Chapter 3: Migrating to a new printer
18
A776 (B780) Programming Guide
A776-PG00001 C 12/09
· For text printing, these are the A721 internal dip switch settings:
3.2
3.3
3.4
Right Margin Text
Text Columns
OFF
OFF
OFF
.5”
33/40
OFF
OFF
ON
.3”
33/40
OFF
ON
OFF
.5”
35/42
OFF
ON
ON
.3”
35/42
ON
OFF
--
.1”
35/42
ON
ON
--
.1”
42/51
· A721 internal dip switch 3.5 applies to the right margin in Page Mode printing. That is handled with another
B780 configuration command.
· The right margin and text columns options cannot be changed separately because some combinations are
not reasonable.
· The B780 (emulating the A721 emulating the Epson 375) powers up with compressed print selected.
Select DH Pitch and Rotated Text Columns
Code (Hexadecimal)
1F 03 25 03 n (DH emulation)
n
DH Pitch
Receipt
Slip
# Lines Rotated
00
33
44
42
19 (default)
01
36
44
42
20
02
40
44
42
21
03
44
44
51
22
04
50
56
51
21
05
57
56
51
22
06
66
56
51
23
· This command corresponds to A721 internal dip switches 2.1, 2.2, and 2.3.
· For rotated text printing on the slip the B780 matches the A721.
· For standard text printing the B780 receipt will print in 44-column mode or 56-column mode. When DH pitch
of 57 columns or 66 columns is selected, text will wrap.
· For standard text printing the B780 slip will print in 42-column mode or 51-column mode. When DH pitch of
57 columns or 66 columns is selected, text will wrap.
· The run-time command for pitch selection (1B 50 n) overrides this configuration setting.
· These are the A721 internal dip switch settings:
2.1
2.2
2.3
DH Pitch
# Lines Rotated
Off
Off
Off
33
19
On
Off
Off
36
20
Off
On
Off
40
21
On
On
Off
44
22
Off
Off
On
50
21
On
Off
On
57
22
Off
On
On
66
23
Select Slip Lines per Inch
Code (Hexadecimal)
1F 03 25 04 n
This command sets the slip station lines per inch setting
.
n
Line spacing
00
7.2 LPI (default)
01
6.0 LPI
This corresponds to the A721 internal dip switch 3.1
