Chapter 4: Programming the Printer
28
A776 (B780) Programming Guide
A776-PG00001 C 12/09
Rotated printing commands
Three commands control the rotation of printing. The table shows the combinations of set/cancel upside down print,
set/cancel rotated print (clockwise), and rotated print (counterclockwise).
Rotated clockwise and rotated counterclockwise print commands are mutually exclusive: the setting of the last received
command is effective. Unintended consequences may result when rotated clockwise is mixed with other commands.
The samples of the print show only the normal-size characters. Double-wide and double-high characters are printed in
the same orientation. They may also be mixed on the same line.
Upside down
Rotated CW
Rotated CCW
Resulting output
(1B 7B n)
(1B 56 n)
(1B 12)
Canceled
Canceled
Cleared
A B C
Canceled
Set
X
Set
Canceled
X
Set
Set
X
X
X
Set
Note: The following print modes cannot be mixed on the same line:
• Standard and compressed pitch
• Vertical (normal) and rotated
• Right-side up and upside-down
• Single-high (normal) and double-high
A B C
A B C
A B C
A
B
C
