Chapter 5: Programming commands 101
A776-PG00001 C 12/09 A776 (B780) Programming Guide
Rotated barcodes set with small modules (select bar code width command 1D 77 n , with n = 1 or 2) and PDF 417
barcodes in any orientation are printed at low speed, for better readability.
Exceptions
The command is only valid at the beginning of a line.
Illegal data cancels the command.
Values:
First variation: String terminated with NUL character. Length k is not specified in command string; it depends on the
bar code being printed.
m Bar code d1...dk length
0 UPC-A 48-57 (decimal) Fixed length: 11,12
30-39 (ASCII numerals)
1 UPC-E 48–57 Fixed length: 11, 12
30-39
2 JAN13 (EAN) 48–57 Fixed length: 12, 13
30-39
3 JAN8 (EAN) 48–57 Fixed length: 7, 8
30-39
4 Code 39 48–57, 65–90 (decimal), 32, 36, 37, Variable length
43, 45, 46, 47 (decimal)
d1 = dk = 42 (start/stop code is supplied by printer if necessary)
30-39 (ASCII numerals), 41-5A (ASCII alphabet)
20, 24, 25, 2B, 2D, 2E, 2F (ASCII special characters)
d1=dk=2A (start/stop code is supplied by printer if necessary)
5 Interleaved 2 of 5 48–57 Variable length (even number)
30-39
6 Codabar 65–68, start code 48–57, 36, 43, 45, 46, 47, 58 Variable length
41-44, start code 30-39, 24, 2B, 2D, 2E, 2F, 3A
10 PDF 417 1–255 Variable length, maximum 1000 characters
01-FF
Second variation: length n specified at beginning of string. Except as noted, 0 < n < 256.
m Bar code d1...dn n
65
UPC-A 48–57 (decimal) Fixed length: 11, 12
30-39 (ASCII numerals)
66 UPC-E 48–57 Fixed length: 11, 12
30-39
67 JAN13 (EAN) 48–57 Fixed length: 12, 13
30-39
68 JAN8 (EAN) 48–57 Fixed length: 7, 8
30-39
69 CODE 39 48–57, 65–90 (decimal), 32, 36, 37, Variable
43, 45, 46, 47 (decimal)
d1 = dk = 42 (start/stop code is supplied by printer if necessary)
Continued . . .
