Chapter 5: Programming commands 115
A776-PG00001 C 12/09 A776 (B780) Programming Guide
Transmit last MICR read
ASCII: ESC w R
Hexadecimal: 1B 77 52
Decimal: 27 119 82
Resends the previously decoded MICR data (as if the parsing has not been defined) to the host. The return
data is defined in the “Read MICR data and transmit” command (1B 77 01) without parsing and presents the data from
the last MICR read since power-up or reset or indicates in the status that no read has yet occurred.
MICR parsing
This section describes MICR parsing in detail and includes several examples of useful parsing variations. It also
describes how to create a parsing format and how to create and maintain an exception table.
Define parsing format, save in NVRAM
ASCII: ESC w P d1 d2 … dn CR
Hexadecimal: 1B 77 50 d1 d2 … dn 0D
Decimal: 27 119 80 d1 d2 … dn 13
Defines and saves parsing format. See parsing parameter string options in this document. Send with this command
the parse data that is to be the default parse string at printer power-up. If no parameters are selected, parsing is not
performed.
d1 through dn are the parse string. The string must be CR terminated. If the string has invalid characters in it or is too
long, the printer will store a null string, and unparsed MICR data will be returned.
Define parsing format, do not save permanently
ASCII ESC w p
Hexadecimal 1B 77 70
Decimal 27 119 112
Defines, but does not save parsing format. See parsing parameter string options in this document. Send as often as
desired to change the previous parse format string.
If no parameters are selected, parsing is not performed.
Same parameters as 1B 77 50....
Parsing parameter string options
Variable length fields
Variable length field name Selector Comments
Transit number T Full 9-digit routing/transit number
Bank number B Digits 4–8 of transit number
Check digit D Digit 9 of transit number
Account number A
Check serial number C Separate from account number
Amount $ This field may not be present or readable
Variable length field Selector Comments
optional modifiers
Zero fill to length 0 ASCII zero preceding maximum length
Maximum length nn 1- or 2-digit ASCII number
Remove space/dash X
Replace space/dash with 0 x
