Clear-Com VOICE2 - Manual (Page 28)

Vitec Group Communications
VoICE IP Interface User Manual
2 - 8
12. Make sure that Use the following IP address is selected (not
Obtain an IP Address automatically).
Figure 2-9: IP Address Selection
13. Change the IP Address to 10.0.0.2 and the subnet mask to
255.0.0.0 (and leave Default gateway blank):
Figure 2-10: Default Gateway
14. Make sure that all of the DNS entries are blank:
Figure 2-11: DNS Entry
15. Click the OK button on the Internet Protocol TCP/IP Settings
window.
16. Click the OK button on the Local Area Connection Properties
window.
17. Click the Close button on the Local Area Connection Status
window.
18. Close the Network Connections window by clicking on the X in
the top right hand corner.
Changing the IP Address of the PC in Windows XP
1. Disconnect your PC from any Ethernet network it may be connected
to.
2. Right-click on My Network Places and choose Properties from the
menu.
