32
Maintenanceandtroubleshooting
Type 8011
10. spAre pArTs AnD
Accessories
attention
risk of injury and/or damage caused by the use of unsuitable
parts.
Incorrect accessories and unsuitable spare parts may cause
injuries and damage the device and the surrounding area.
• Use only original accessories and original spare parts from
Bürkert.
spare part order code
seal for metal fitting (Fig. 15)
FKM (DN6 to DN65)
426340
EPDM (DN6 to DN65) 426341
set of 2 o-rings for the end pieces (true
union connections only) + 1 flat seal and 1
o-ring for the se11 electronic module con-
nection (Fig. 16)
FKM - DN8
448679
FKM - DN15 431555
FKM - DN20 431556
FKM - DN25 431557
FKM - DN32 431558
FKM - DN40 431559
FKM - DN50 431560
spare part order code
EPDM - DN8 448680
EPDM - DN15 431561
EPDM - DN20 431562
EPDM - DN25 431563
EPDM - DN32 431564
EPDM - DN40 431565
EPDM - DN50 431566
Set of screws: 4 short screws (M4x35 - A4) + 4
long screws (M4x60 - A4)
555775
Accessory order code
5-pin M12 female connector, moulded on
shielded cable (2 m)
438680
5-pin M12 female connector, to be wired 917116
Fig. 15: Seal for metal fitting
