Burkert Type 8011 User Manual
Page 12

12
Technicaldata
Type 8011
Cable
35
68
40
46
60
50
L = 1 m
Fig. 1: Dimensions of the SE11 module
Tab. 1: Dimensions of the 8011 with internal thread connections
acc. to G, Rc, NPT, in stainless steel or brass
Dn [mm]
p [mm]
A [mm]
D [inch]
l [mm]
15
57.5
84.0
G
1/2
NPT 1/2
Rc 1/2
16.0
17.0
15.0
20
55.0
94.0
G
3/4
NPT 3/4
Rc 3/4
17.0
18.3
16.3
25
55.2
104.0
G
1
NPT 1
Rc 1
23.5
18.0
18.0
32
58.8
119.0
G 1 3/4
NPT 1 3/4
Rc 1 3/4
23.5
21.0
21.0
40
62.6
129.0
G
1 1/2
NPT 1 1/2
Rc 1 1/2
23.5
20.0
19.0
50
68.7
148.5
G
2
NPT 2
Rc 2
27.5
24.0
24.0
A
L
D
P
Tab. 2: Dimensions of the 8011 with external thread connections
acc. to SMS 1145, in stainless steel
Dn [mm]
p [mm]
A [mm]
D [inch]
25
55.0
130
Rd40 x 1/6"
40
58.8
164
Rd60 x 1/6"
50
62.6
173
Rd70 x 1/6"
English
