9
TechnicalData
6. technical Data
6.1. conformity
In accordance with the EC Declaration of conformity, the electromotive
rotary actuator type 3003 is compliant with the EC Directives.
6.2. standards
The applied standards, which verify conformity with the EC Directives,
can be found on the EC Type Examination Certificate and/or the EC
Declaration of Conformity.
6.3. Operating conditions
Ambient temperature: -10 °C ... +55 °C
-10 °C ... +40 °C (Emergency
reset)
Permissible areas of application: 0 ... 2000 m altitude
Permissible humidity: < 81 % to 31 °C (88 °F) with
linear decrease as far as 50 % at
40 °C (according to EN 61010-1)
Protection class: IP66 with cable bushing
6.4. general technical data
6.4.1. mechanical data
Dimensions: See data sheet
Weight: 1.3 kg (20 Nm)
2.8 - 3.1 kg (35-100 Nm)
materials
Cover: Nylon
Body: PA (Nylon with glass fibre)
Axis / screws: Stainless steel
Gears: Stainless steel and PC (Polycarbonate)
Actuating angle: 90° ± 5° (optional 180°, 270°)
Duty cycle: 50 % at max. torque
6.4.2. electrical data
Electrical connections: Cable bushing according to
EN 175301-803
Cable gland ISO M20
Limit switches: 4 adjustable (2 for the motor and 2 addi-
tional ones for feedback signal) -
max. 250 V AC / 5 A
