10
TechnicalData
electrical data for version without analog input signal:
torque
90° posi-
tioning time 1)
(Specifica-
tions under
load)
power
consumption
Voltage / frequency
20 12 s 15 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
35 7 s 45 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
60 12 s 45 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
100 23 s 45 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
1) Other positioning times on request
2) The operating voltage must not drop below 11.5 V
We recommend an actuator designed with 1.5 times the
maximum torque of the fitting (On/Off).
electrical data for version with analog input signal:
torque
90° posi-
tioning time 1)
(Specifica-
tions under
load)
power
consumption
Voltage / frequency
20 25 s 15 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
35 40 s 45 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
60 79 s 45 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
100 119 s 45 W 15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
1) Other positioning times on request
2) The operating voltage must not drop below 11.5 V
We recommend an actuator designed with 2 times the
maximum torque of the fitting (analog input signal).
english
Type 3003
