Deutsch, 4technische daten – Burkert Type 8624 User Manual
Page 50

48 - 8624-2 Standard
deutsch
4
TECHNISCHE DATEN
Betriebsspannung
24 V DC
Leistungsaufnahme
max. 0,3 W (ohne Proportionalventil)
Ausgangsstrom (zum Ventil)
max. 1,0 A
Betriebstemperatur
- 10 ... + 60 °C
Störfestigkeit
nach EN50082-2
Störaustrahlung
nach EN50081-2
Eingänge
1 Sollwerteingang
4 - 20 mA bzw. 0 - 10 V, einstellbar
1 Istwerteingang
4 - 20 mA bzw. 0 - 10 V, einstellbar
Auflösung für beide Eingänge
10 Bit
Eingangsimpedanz (4 - 20 mA)
< 200
Ω
Eingangsimpedanz (0 - 10 V)
> 300 k
Ω
Ausgang
PWM-Ausgang
24 V - pulsweitenmoduliert
Regler
Regelalgorithmus
PI-Regler
Abtastzeit T
A
27 ms
Verstärkungsfaktor K
P
0 - 10,00
Nachstellzeit T
N
0,05 - 200,1 s
Skalierung der Regelgröße
0,000 - 9999
Gehäuse
Kabelabgang
in 90° - Schritten drehbar
Schutzart
IP 65
Werkstoff
Polyamid
Abmessungen (B x H x T)
54 x 54 x 61 mm
Bestell-Nr.
143 570
