iVMS-2000 User Manual
66
(1)Add map link
Click the [Add map link] button in edit state to pop-up the dialog.
(Figure 5-9) Input the name of map link in [Name] bar. Select the associated map in
[Associate] map list. Click [OK] to add map link.
Figure 5-9 Map Link
(1)Delete map link
Select a link in Map Preview Area in edit state. Click [Delete selected] to
pop-up the dialog. (Figure 5.9) Click [OK] to delete the map link or click [Cancel] to
cancel delete operation.
(2)Modify map link
Right click on the map link in edit state to pop-up the right button menu .
Click [Property] to pop-up tips Figure 5-9. Change the name of the map link in the [Name]
bar. Re-select the associated map in [Associate] camera list. Click [OK] to modify the map
link or click [Cancel] to cancel the modify operation.
Note: Double click the added map link in Map Preview Area in non-editing state can
directly turn to the associated map of the map link.
5.1.4 Alarm Spot Operation
Alarm spot: The associated alarm input of an area in the map. (Such as: Audio sensors,
Infrared sensors.)
(1)Add alarm spot
