iVMS-2000 User Manual
96
6.7.1 SMS Configuration
Users can configure COM port and mobile phone number to receive the short message in
the SMS configuration interface, and the SMS configuration is related to the SMS alarm
linkage configuration.
A GSM/GPRS modem is required for SMS function (Please refer to the installation guide of
GSM/GPRS Modem for its configuration steps). After the modem is connected and its driver is
installed, users can read the COM port number for the modem in “Device Manage” of Windows
OS. Please input the COM port info and mobile phone number in iVMS-2000 configuration
interface, and click [OK] after testing.
Notes: The COM port for SMS cannot be duplicated with COM port for PTZ or alarm
box.
6.7.2 PTZ COM Port Configuration
Users need to configure the PTZ connection port for iVMS-2000, and click [Save]. For the
other PTZ configurations, such as PTZ protocol, address and COM port data information can
be configured under Camera configuration.
Notes: The COM port for PTZ cannot be duplicated with COM port for SMS or alarm
box.
6.7.3 Alarm Box Configuration
Add/ Modify/ Delete local or network alarm box.
[Add Alarm Box]
Add local sensor input and replay output (Figure 6-41) and configure COM port
information, such as sensor input port and relay output port. Users can test the I/O
signals while adding alarm box information. For [Check Sensor] function, users need to
connect sensor input devices on the alarm box; and for [Check Relay], users need to
click each icon under this button to test the relay output for the alarm box.
